Al Amal Hospital

The densest ceiling void in construction, cleared before a hanger went up. Architecture, structure and MEP federated into one model, and every service zone closed out digitally before installation began.

BIM coordinationMechanicalElectricalStructural designArchitectural
Rendered street elevation of the medical centre.

At a glance

Location
Abha, KSA
Scope
Interior design + BIM

Outcome

The brief

Healthcare service zones carry medical gas, HVAC, drainage, power and data through the same corridors, with no tolerance for a clash found on site.

The constraint

Every service in a hospital corridor sits on another trade's critical path. One conflict found at installation does not stop one crew; it stops the crews on either side of it as well.

What we delivered

  • Federated BIM model assembled from the architectural, structural and MEP disciplines
  • Systematic clash detection across every service zone in Navisworks
  • Conflicts resolved digitally before installation began
  • Coordinated ceiling-void sections issued to each trade contractor
  • As-built model maintained through construction for facility handover

Project images

Front elevation render with the main entrance and drop-off.
Front elevation render with the main entrance and drop-off.
Cutaway 3D of the first floor showing clinics, waiting areas and circulation.
Cutaway 3D of the first floor showing clinics, waiting areas and circulation.
Interior render of a consultation clinic.
Interior render of a consultation clinic.
Interior render of the emergency treatment bay.
Interior render of the emergency treatment bay.
Interior render of the X-ray imaging room.
Interior render of the X-ray imaging room.

Related projects

Aerial rendering of the factory within the industrial area.

SBF Factory

Factory buildings designed across architecture, structure, MEP and Civil Defense systems, with a coordinated IFC model and design visuals…IndustrialRiyadh, KSA Cutaway BIM model of the ground floor with MEP services.

Qortoba Offices

Electrical design for an office building in Riyadh: power distribution from the ground-floor electrical rooms to every floor, modelled in…CommercialRiyadh, KSA Exterior render of the data centre office block, option 1.

center3 JDC205, Jeddah

Chilled-water and roof MEP shop-drawing packages, and the architectural axonometric set for the C3DCI-JDC205 series.Data centresJeddah, KSA2025
