Mechanical
HVAC, plumbing and plant-room design balanced against comfort, code compliance and what the building will cost to run.
Mechanical drawings coordinated, priced and formatted for the reviewer who has to approve them.
Who this is for Contractors, developers and technical offices needing a mechanical package taken from load to layout.
Price this scopeWhat you receive
Cooling and heating load calculation
A room-by-room load model with the design conditions, envelope data and occupancy stated, so a reviewer can rerun it.
System selection and equipment schedules
The system chosen against capital cost, running cost and maintenance access, with schedules a procurement team can price.
Ductwork and pipework layouts
Sized, routed and coordinated against structure and the other services, at the levels the installer sets out from.
Plant room and chilled water design
Plant layout, hydraulic design, pump selection and the maintenance envelopes the plant will actually need.
Control philosophy and sequence of operation
Written so the controls contractor can program from it and the commissioning team can test against it.
Piping isometrics for prefabrication
Spool drawings issued for off-site fabrication, with the joint types and supports called out.
The scope, at a glance
-
Cooling and heating loads
Cooling and heating loads to ASHRAE and SBC 501, computed in Carrier HAP.
-
HVAC design and sizing
Equipment selection, ductwork sizing and equipment schedules.
-
HVAC system design
Chilled water, VRF, split and packaged DX system design.
-
Plumbing systems
Domestic water, hot water, drainage and venting.
-
Fire protection
Firefighting to NFPA 13, 14 and 20: sprinklers, standpipes and pumps.
-
Smoke management
Smoke management and stairwell pressurisation to NFPA 92.
-
Pump and tank design
Pump sizing, water tank sizing and pressure boosting.
-
Energy modelling
Energy modelling for SBC 601, Mostadam and LEED compliance.
- Code-compliant ASHRAE, SBC, NFPA and the local authority.
- Efficient and reliable Systems balanced for performance and running cost.
- Coordinated design Integrated with the structure and the other services.
- Sustainable Energy-efficient design, evidenced.
HVAC, plumbing and plant-room design balanced against comfort, code compliance and what the building will cost to run.
How it is produced
Loads before layouts
Nothing is routed until the load model is settled. Re-routing a duct because a load moved is the commonest avoidable rework.
Running cost is a design input
Efficiency is compared at selection, not reported after. SBC 601 and ASHRAE 90.1 set the floor, not the target.
Coordinated in the federated model
The mechanical model is federated with structure and the other services as it is drawn, not once it is finished.
Maintenance access is drawn
Coil pull, filter access and valve reach are modelled as volumes, because a plant room that cannot be serviced fails on year two.
Projects delivered under this service
7 projects
center3 JDC205, Jeddah
Chilled-water and roof MEP shop-drawing packages, and the architectural axonometric set for the C3DCI-JDC205 series.Data centresJeddah, KSA2025
Al Amal Hospital
The densest ceiling void in construction, cleared before a hanger went up. Architecture, structure and MEP federated into one model, and…HealthcareAbha, KSA
Taya Industrial City
An industrial city's utility corridors, resolved before excavation. Site-wide electrical network design, street lighting verified in…InfrastructureRiyadh, KSA
ZHI Headquarters
LEED BD+C consultancy for a Jeddah headquarters: 80 of 110 points on the published scorecard, carried by energy, materials, daylight and…CommercialJeddah, KSA
SBF Factory
Factory buildings designed across architecture, structure, MEP and Civil Defense systems, with a coordinated IFC model and design visuals…IndustrialRiyadh, KSA
Cool-Wall Coating: Comparative Energy Study
Two identical EnergyPlus models of a Riyadh office, differing only in wall-finish optics: 33.4 °C off the peak wall temperature and 12,040…CommercialRiyadh, KSASoftware
- Revit MEP
- HAP
- Pipe Flow Expert
- IESVE
- Navisworks
Standards and codes
- ASHRAE 90.1
- ASHRAE 62.1
- SBC 501
- SBC 601
- SMACNA
- NFPA 90A
What the deliverable is
- Revit model
- DWG layouts
- Load calculation PDF
- Equipment schedules XLSX
- Piping isometrics
Deliverables
Pick a discipline and tick what you need. Send the selection and its indicative budget range appears on screen and arrives in your inbox.
| Deliverables | Unit |
|---|---|
| Mechanical / HVAC design: commercial | per m² |
| Chilled water / plant room design | lump sum |
Questions clients ask
Do you design for Civil Defence and municipality review?
The drawings are formatted for that review from the first issue, and comment responses are handled through to approval.
Can you value-engineer an existing mechanical design?
Yes. We rerun the load model first: most savings come from a load assumption nobody revisited, not from downsizing equipment.
Do you produce the energy model as well?
Yes, and it is priced under LEED and green building. The mechanical model feeds it, so the two describe the same systems.
A question that is not here?
Ask the engineer who would run your project. Send the drawings and the answer comes back in writing.
Send us one package.
Send a package and you get a scope, a fixed price and a delivery date within two working days.
Related services
Electrical
Load strategy, distribution, lighting verified in DIALux, and earthing and lightning protection studies that stand up to review.
LEED and green building
Hit your LEED and Mostadam targets with no surprises. Credits engineered into the design, evidence ready before the reviewer asks, and every comment…
Steel structures
